CHN141-20

Click image to enlarge
0.000
Quantity:

Pin, Non-Heat Treated Steel, Finish: Zinc, 0.141 x 1.25
CH_CHN_CHS_CHA

CHN141-20 Specifications

  • Type: Unified
  • Thread Size: Unthreaded
  • Material: Steel, Non Heat Treated
  • Finish: Zinc Clear
  • Sheet Min.: 0.040
  • Hole Diameter: 0.163 +0.003 -0.000
  • B: 0.240 ±0.015
  • D: 0.141 ±0.002
  • L: 1.250 ±0.015
  • X Max.: 0.090
  • CL to Edge Min.: 0.28
